The Wanco Hybrid Diesel Light Tower uses a rechargeable battery to power four dimmable LED lights. When battery power runs low, the diesel genset kicks in automatically to fully recharge the battery. Highly efficient performance uses far fewer engine hours, saving fuel, maintenance, labor and cost. Selectable shore power is standard.
A lithium-ion battery powers four dimmable LED lights. When the battery charge runs low, the engine starts automatically, shutting down when the battery is fully charged. The DSE digital controller allows manual on/off or automatic operation with the flip of a switch.
The rechargeable lithium iron phosphate (LFP) battery powers the lights at full brightness for seven hours on a full charge. With infinite brightness adjustment from 0 to 100%, longer run time is possible on battery power alone.
The genset combines a Kubota or Mitsubishi Tier 4 diesel engine and 4kW Mecc Alte alternator. Together with the 60-gallon onboard fuel tank, hybrid operation runs up to 1400 hours before refueling with the lights at 50% brightness.
As an alternative to diesel, a shore power input switch is standard. Connect the light tower to an external AC power source to charge the battery silently.
Features
- Rechargeable lithium-ion battery power
- Dimmable 200-watt LED lights
- 7-hour battery at full brightness
- Easily switch between diesel and shore charging
- Save fuel, maintenance, labor and cost
Tower
- 23-foot telescoping tower
- 200W dimmable LED lights
- Infinite brightness adjustment from 0 to 100%
- Aim lights from the ground
- Power-operated tower winch
Controls
- DSE controller for manual and automatic operation
- Battery monitor provides the most useful power information including true battery state-of-charge
- Bluetooth app for local remote monitoring
- Convenient time remaining feature
Power
- Lithium iron phosphate (LFP) battery powers the lights
- Up to 7 hours at full brightness on battery power
- Up to 1400 hours on a single tank of diesel fuel at 50% brightness
- Selectable diesel genset or shore power for battery charging
- Kubota or Mitsubishi T4 engine and 4kW Mecc Alte alternator
- 120V convenience outlet with genset power
- Genset recharges battery in 3 hours
Trailer
- Three outriggers and four leveling jacks provide stability
- Fold-up tow bar for compact storage
- All-welded galvanized structural steel frame
- Heavy gauge all-steel body
- 60-gallon onboard fuel tank
Options
Tower lift
- Manual winch
- Hydraulic tower
Engine
- Kubota
- Mitsubishi
Transport
- Heavy-duty axle
- Torsion axle
- Combo tow hitch
- Lunette ring for pintle hook
- LED taillights
Other options
- Electronic fuel sensor
- Cold-weather package
- Emergency shutdown
Some options may not be available for aftermarket installation. Please consult factory.
Weight
Operating
Approx. 1885 lb (855kg)
Shipping
Approx. 1500 lb (680kg)
Construction
Trailer
MIG welded, unibody-style
Finish
Trailer: Hot-dipped galvanized
Cabinet: Oven-baked powder coat
Tow hitch
Standard 2-inch ball coupler
Tires
ST175/80R13 radials
Lights
Light fixtures
Four adjustable light fixtures
Dimmable LEDs with infinite dimming from 0% to 100%
Luminous flux @100% brightness
32,045 lumens per fixture
128,180 total lumens
Coverage area*
26,510 sq. ft. (2460 m²) 0.6086 acres
Power draw
200 watts per light fixture
Light height
23 feet (7 meters) fully extended
Lights operate at any height
Power System
Battery
One 24Vdc rechargeable lithium-ion (LFP) battery
Battery capacity
230 Ah @ 24Vdc
Engine type
Tier 4 Final diesel, 2-cylinder, 4-cycle, liquid cooled
Engine speed
1800 rpm
Generator type
Brushless, class H
Generator wattage
4.0 kW
Start battery
12 Vdc AGM, 575 CCA
Max. power output
Kubota: 5.6 hp (4.2 kW)
Mitsubishi: 9.0 hp (6.7 kW)
Displacement
Kubota: 29.20 in³ (479 cm³)
Mitsubishi: 38.75 in³ (635 cm³)
Sound level, max. load
68 dB @ 23 ft (7m)
Fuel tank capacity
60 gal (227 L)
Fuel consumption
Kubota: 0.22 gal/hr (0.83 L/h)
Mitsubishi: 0.23 gal/hr (0.87 L/h)
Runtime before refueling
Lights at 100% brightness
Kubota: approx. 700 hours
Mitsubishi: approx. 500 hours
*Total coverage ≥ 0.5 fc with lights at 23 feet (7 meters) and 100% brightness, fixtures tilted 15 degrees down from vertical.
Specifications subject to change without notice.
