X-Marker Runway Closure Signal

WTRC

The Wanco X-Marker is an L-893 temporary runway closure signal that efficiently and effectively warns pilots of closed airport runways and taxiways, and protects maintenance crews working in these areas. Proven technology, the X-Marker is in extensive use at airports today.

See More Detail

The Wanco X-Marker Runway Closure Signal is a lighted visual aid for indicating to airplane pilots that an airport runway is closed. Designed in accordance with FAA requirements, its flashing lights can be seen both day and night from miles away, clearly discernable as a giant “X” and distinguishable from other lighted visual devices used at airports, signifying that the runway is not open for landings. The X‑Marker trailer is easy to transport, and can be deployed by one person in less than five minutes.

The “X” shape comprises nine lights on four independent arms and a mast. When deployed, the mast tilts upward nearly to vertical, and the “X” is centered at the top of the mast. For transport and storage, mast tilts downward and the arms pivot together. The entire assembly lies flat when stowed, held in place by support brackets and lock-pins.

Each arm includes two high-efficiency LED light fixtures, with one additional light fixture located at the center of the “X.” LEDs provide highly directional light distribution, resulting in high luminosity and low power consumption.

System power is provided by batteries, which are charged continuously by a diesel engine. The system can run continuously for more than a week without intervention or refueling, and the batteries continue to power the lights if the engine shuts down.

The power system is housed in a weather-resistant enclosure that has two side doors for easy access. For complete access to the engine, generator, and electrical components, the enclosure has a hinged top panel that rises with the “X” assembly when maintenance is required. The side doors may be opened while the maintenance panel is raised, further enhancing access. An integrated secondary-containment system protects against fluid leaks, spills, and drips.

Features

  • 9 high-efficiency LED lights provide visibility at long distances
  • Extremely portable, can be towed by most vehicles
  • Easy setup in less than 5 minutes
  • Lockable control box and engine cage
  • Perkins industrial diesel engine with 30-gallon fuel tank
  • Approximately 168 hours of continuous operation on a single tank of fuel

Transport

  • Compact trailer is easy to maneuver
  • Torsion axle provides smooth ride and reduces stress on components
  • Cradles with locking pins hold display arms in place during transport

Setup

  • Heavy-duty hand-winch allows one person to easily raise and lower “X” assembly
  • Lock-pins hold the assembly in place during operation
  • Two outriggers and five leveling jacks provide stability
  • Full deployment by one person takes less than five minutes
  • Integral secondary containment eliminates the need for an external containment sump

Operation

  • Fully enclosed steel equipment-bay protects controls, engine, and other components from the elements
  • Two gull-wing doors with handles and latches provide access to controls, fuel tank, engine, and electronics
  • Door latches accept user-supplied padlocks to protect equipment bay from unauthorized access
  • Control panel features elapsed hour meter, engine indicator lights, and brightness-selection switch
  • Manually activated high-power operating mode melts ice from lights

Lights

  • High-efficiency LED lights provide bright, highly directional light
  • Lights are instant-on and immediately at full intensity
  • Flashing front-facing lights are visible for miles, day or night, even in poor weather
  • Flashing rear-facing indicator lights allow operator to see the equipment is operating

Power system

  • Ultra-quiet industrial diesel engine, 3-cylinder and water-cooled
  • Energy-efficient operation results in extraordinarily long run times
  • Engine properly sized for low-wattage load of high-efficiency LED lights
  • Engine size prevents wet stacking, ensuring higher efficiency and no waste
  • Extra-large polypropylene fuel tank shows fuel-level at a glance, no need for fuel gauge
  • Fuel tank has wide filler neck for convenience
  • Automatic engine-shutdown system protects engine from damage due to low oil pressure and high coolant temperature
  • Batteries continue to power lights after engine fuel runs out

Maintenance

  • 50,000-hour LED lifespan reduces maintenance by virtually eliminating the need for replacement
  • Hinged maintenance panel provides unimpeded access to engine, generator and electrical components
  • Durable powder-coat finish resists the elements
  • Standard trailer tires
  • Heavy-duty bolt-on steel fenders can be replaced if damaged

Applications

  • Lighted visual indication of temporary closure of airport runway
  • Can also be used for airport taxiways

Options

Transport

  • 2-inch ball coupler tow hitch
  • Standard lunette ring for 2 1/2-inch pintle hook
  • Heavy-duty lunette ring for 3-inch pintle hook
  • Tandem tow package
  • Oversized forklift channels

Accessories

  • Sensor-controlled electric fan
  • Cold weather package
  • Emergency stop

Some options may not be available for aftermarket installation. Please consult factory.

Specifications

Physical

Construction

Fully enclosed steel equipment bay
All welded structural steel trailer
Tie-downs on corners of trailer frame
Bolt-on steel 16ga fenders

Finish

Oven-baked powder-coat finish
Trailer and equipment cabinet are black
Arms are “aviation yellow”

Weight

Approx. 1980 lbs. (898kg)

Tires

ST185/80D13

Tow hitch

Combo-hitch for 2-inch ball and 2 1/2-inch pintle hook

Lights, front

Lamp type

High-efficiency LEDs

Number of fixtures

Nine LED light fixtures

Luminosity

3500 lumens per fixture
31,500 lumens total

Color

5700K daylight

Wattage

42 watts per fixture when on, zero watts when off
378 watts total

Flash rate

2.5 sec on, 2.5 sec off

Lights, back

Lamp type

Sealed 2-diode LED light, surface-mount

Lens

2 1/2 × 3/4 in. (6.6 × 1.9cm)

Wattage

0.1W

Control system

Location

Inside equipment bay

Enclosure

Powder-coated 16ga steel

Controls

Toggle switch for lights:
On at full brightness
On with automatic brightness
Off

Indicators

Indicates engine status conditions:
High-temperature shutdown
Low oil pressure
Attention required

Low-voltage disconnect

Engages when battery voltage drops to 21.48Vdc
Lights strobe at ~2% duty cycle

Power system

Engine

Perkins 403D-07 industrial-grade Tier 4 diesel engine

Generator

Mecc Alte 5.2kW 60Hz

Fuel consumption

Approx. 0.21 gal./hr (0.79L/hr)

Fuel tank capacity

30 gal. (114L)

Run time

On engine, approx. 168 hours per tank of fuel
On batteries only, after engine shutdown, up to 24 hours

Batteries

Two 4D AGM 12Vdc batteries, wired for a 24-volt system

specification image

Specifications subject to change without notice.
