Mini Solar Integrator Trailer

WCTS-SM-730W Mini Integrator

Download Brochure

The Wanco Mini Integrator Trailer is a compact version of our full-size integrator trailers, providing the same robust and dependable platform for your gear. This versatile system lets you combine cameras, lights, recording devices, audio systems, communications, RF radios and more — anything needed to keep your job site secure. System power is supplied by batteries, which are charged automatically by the solar‑based charging system.

See More Detail

Integration

Installing your equipment is easy with cabling already factory-installed on the tower. A large equipment mounting tray inside the battery box is ready for your electronics and controls. Standard electrical and mechanical connectors make installation simple.

Built to Last

Just like our full-size trailers, the Mini Integrator is built to last, with a heavy‑grade structural steel frame and a reliable power system. Wanco trailers are designed for on- and off-road use. Components are chosen for durability and dependability, ensuring reliable operation and long lifespan. Many components are replaceable when necessary, such as the trailer’s bolt-on fenders.

Power Efficient

System power is supplied by batteries, which are charged automatically by the solar-based charging system. The power system operates silently. The battery bank is housed in a high‑security enclosure with hidden hinges and hidden-shackle puck locks.

The solar array features adjustable-tilt for optimal charging. Monocrystalline half‑cut cell solar panels significantly increase the power yield over traditional solar technology. The system employs a state-of-the‑art Smart MPPT controller to maximize every available amp for up to 30% more charging capacity. Solar yield calculations for your location are available from the factory. Contact us to learn more.

An AC charger is included and can plug into a portable generator or shore power. Applications with less sun or greater power needs may require an external charge.

Features

  • Compact and easy to transport
  • Add your own electronics
  • Built-in power system
  • Rugged trailer built for integrators
  • Silent operation
  • Environmentally friendly

Base Platform

  • All-welded structural steel frame
  • Folding drawbar for compact storage
  • Telescoping 20-foot tower rotates nearly 360 degrees
  • Manual hand-operated tower winch
  • Two pendant mounts include 1.5-inch NPT fittings
  • Three Cat 5e cables and one 16/2 power cable
  • Onboard 24Vdc power system

Electronics

  • Electronics and controls are housed in the battery box
  • Equipment mounting tray is 15 inches deep by 30 inches wide with 3.5 inches clearance height
  • High-security battery box features heavy-gauge steel construction, a hinged top panel with hidden hinges and two hidden-shackle puck locks

Power System

  • 12Vdc AGM batteries wired for 24 volts
  • 730 W solar array
  • 400 Ah battery bank in one battery box
  • Solar array tilts from horizontal to nearly vertical with manual hand-crank
  • Smart MPPT solar charge controller
  • Bluetooth mobile app for remote power system monitoring
  • AC-charger
  • Automatic low-voltage shutdown protects batteries and sensitive electronics

Power Management

  • True battery state-of-charge
  • Convenient time-remaining feature
  • Remote power monitoring & management
  • Bluetooth app for local remote control
  • Extensive performance history

Battery Monitor

Local battery monitor
A battery monitor inside the battery box gives local access for viewing the most useful power information in real-time.
Basic power management user-interface

Remote power monitoring and control
Remote power management provides a snapshot view of power performance, allowing you to monitor, manage and optimize the power system remotely. The system connects briefly and automatically uploads data to the cloud at 15-minute intervals. Set alerts and alarms to catch potential issues early. Use data to make informed decisions and adjust system operation when needed.
Bluetooth phone app interface

Bluetooth power management
The remote power management app for iOS and Android mobile devices provides real‑time access to the functions described above for remote power monitoring and control. The app connects only within Bluetooth range of the surveillance system.

Options

  • Multi-pendant mount with Nycoil cable protection
  • Choice of NPT fittings
  • Choice of cables
  • AC power inverter

Specifications

Weight

Approx. 1550 lbs. (703 kg)

Construction

Trailer

All welded structural steel

Finish

Oven-baked powder coating

Drawbar

Folding drawbar

Tow hitch

2-inch ball coupler

Tires

ST205/75D15

Power System

Batteries

Four 4D AGM 12 Vdc batteries, wired as a 24-volt system

Battery capacity

400 Ah total

Battery charger

50 A, 24 Vdc

Solar array

730-watt capacity
Manual hand-crank adjustable tilt

specification image

Specifications subject to change without notice.

Contact us today for more information.
