Small Solar Light Towers

WLTS‐SM

Download Brochure

Wanco’s Small Solar Light Tower features a compact trailer and fixed-brightness LED lights. Perfect for lighting areas up to 11,000 square feet, common applications include utility site and road repairs, security checkpoints and gated entrances, flagger stations and personal work areas. Solar light towers operate silently, which makes them perfect for use in residential areas without disturbing the public.

See More Detail

This light tower features four highly efficient LED light fixtures on a 20-foot telescoping tower. The tower rotates nearly 360 degrees without lowering the lights, which operate at any height. The lights can be individually aimed without the use of tools, and they stay where you point them. The tower remains vertical at all times, and the trailer’s low center of gravity keeps the tower stable.

Batteries provide power and an automated solar-based charging system keeps the batteries charged. Functions include manual control and a selection of automatic modes that include dusk-to-dawn operation. Autonomous operation is possible spring, summer and fall.

Features

  • Bright energy-efficiency lights
  • Telescoping 20-foot tower
  • Compact trailer
  • Deploys with a single hand-crank winch
  • Automatic and manual operating modes
  • Photocell-controlled auto-on/off
  • Silent operation
  • Battery powered
  • Automatic solar charging
  • Adjustable-tilt solar array
  • All welded structural steel trailer
  • Folding drawbar for compact storage
  • Maintenance-free AGM batteries
  • Heavy-duty secure battery box

Options

  • 7-day digital timer
  • Standard lunette ring for 2 1/2-inch pintle hook
  • 25-foot extension cable for AC charger
  • Asset Tracker for GPS location

Some options may not be available for aftermarket installation. Please consult factory.

Downloads

Latest product documents only. For older product documentation, please contact our customer service department.

Specifications

Download Full Specs
Weight

Approx. 1550 lbs. (703 kg)

Construction

Trailer

All welded structural steel

Finish

Oven-baked powder coating

Drawbar

Folding drawbar

Tow hitch

2-inch ball coupler

Tires

ST205/75D15

Lights

Light fixtures

Four adjustable light fixtures

Luminous flux*

8715 lumens per fixture
34,860 total lumens

Coverage area**

8200 sq. ft. (762m²)
0.1883 acres

Height

20 feet (6.1m) fully extended
Lights operate at any height

Power draw

60 W per fixture

Power System

Batteries

Four 4D AGM 12 Vdc batteries, wired as a 24-volt system

Battery capacity

400 Ah total

Battery charger

40 A

Solar array

730-watt capacity
Manual hand-crank adjustable tilt

specification image

*Fixed brightness, light fixtures are not dimmable.

**Total coverage ≥ 0.5 fc with fixtures tilted 15° down from vertical.

Specifications subject to change without notice.
